PRODUCT INFORMATION
PRODUCT FEATURES
◆ Bi-color LED: Red+Green. Other colors can be customized.
◆ Water clear colloid or frosted colloid is optional.
◆ Energy saving and environmental friendly. Use epoxy resin for colloid.
◆ Ultra long life and stable output.
◆ High luminous intensity and low light decay.
◆ Quick lit.
◆ Adopt high quality bracket and 99.9% gold wire.
PRODUCT PARAMETERS
| Size | Lens Color | Emitting Color | Forward Voltage (V) | Dominant Wave length (nm) | Luminous Intensity (mcd) | |||
| min | max | min | max | min | max | |||
| ø3mm | Water clear/Frosted | Red | 1.8 | 2.3 | 620 | 640 | 200 | 400 |
| ø3mm | Water clear/Frosted | Yellow | 1.8 | 2.3 | 585 | 595 | 200 | 500 |
| ø3mm | Water clear/Frosted | Bule | 2.9 | 3.5 | 460 | 475 | 200 | 500 |
| ø3mm | Water clear/Frosted | Green | 2.9 | 3.5 | 500 | 535 | 500 | 800 |
| ø3mm | Water clear/Frosted | White | 800 | 1500 | ||||
APPLICATION
It applies to decoration lighting, advertisement lighting, stage lamp, indicator and electrical products, digital products, automatic electronics, electrical appliance and so on.
